Details
Ultra-light, size-specific optimized full Hollow Core Carbon frame featuring leading-edge carbon fiber materials and Pivot's proprietary molding technology for a lighter frame and higher stiffness to weight ratio
Ultra-adjustable custom tuned Fox DPX2 rear shock with all-new internals
Compatible with both 29, 27.5+" and 27.5+” rear/29” front (reverse mullet) wheel sizes without compromise thanks to the adjustable geometry
142mm of supple-yet-efficient dw-link™ suspension
Large water bottle fits inside all size frames
Fits tires up to 29x2.6” or 27.5x2.8” wide
Full Fox Live Valve integration and build options
Progressive geometry with short seat tubes for long travel dropper posts.
Equipped with a 44mm offset 160mm-travel Fox 36 FIT Grip2 Factory and Performance Series forks
Flip-chip upper linkage mount for adjustable geometry in seconds
Fits riders between 5’ and 6'7"
Hassle-free, full-length, internal cable routing with Pivot’s easy to service and silent Cable Port System
Specs
Frame | Carbon fiber front and rear triangle. Alloy suspension linkage |
---|---|
Fork | Fox Factory 36, 44mm offset, GRIP2, 160mm travel |
Headset | Pivot Precision Sealed Cartridge - Tapered - ZS 44/56mm |
Rear Shock | Fox Factory Float DPX2 185x55 Trunnion |
Axles | 15x110 front, 12x157 rear |
Rims/Wheels | DT Swiss XM1700, 30mm internal width, 29-inch |
Hubs | DT Swiss 350, 36-tooth start ratchet |
Spokes | DT Swiss Competition |
Tires | Maxxis Minion DHF 29x2.5 WT TR 3C EXO+ MAXXTERRA (Front), Maxxis Minion DHRII 29x2.4 WT TR 3C EXO+ MAXXTERRA (Rear) |
Crankset | Race Face Effect R 32t, 175mm arms |
Chainrings | 32-tooth Race Face |
Bottom Bracket | Race Face BB92 |
Chain | Shimano CN-M8100 12-speed |
Front Derailleur | Front Derailleurs are Dead |
Rear Derailleur | Shimano XTR M9100 SGS 12-speed |
Cassette/Rear Cogs | Shimano XT M8100 10-51-tooth |
Shifters | Shimano XT M8100 ISPEC EV 12-speed |
Handlebars | OneUp Components Carbon Bar 20mm Rise 780mm wide |
Tape/Grips | OneUp Components |
Stem | Pivot Alloy 50mm |
Brake Levers | Shimano XT M8120 4-Piston |
Brakes | Shimano XT M8120 4-Piston |
Pedals | N/A |
Saddle | Selle Italia |
Seat Post | Fox Transfer Factory Stealth |
Accessories & Extras | One Free complete Tune Up! |
* Subject to change without notice.
